JWST's Integrated Science Instrument Module mounted on a test frame

JWST's Integrated Science Instrument Module mounted on a test frame


Date: 30 January 2014
Satellite: James Webb Space Telescope
Depicts: James Webb Space Telescope's (JWST) Integrated Science Instrument Module (ISIM) mounted on a test frame
Copyright: NASA / Chris Gunn

The James Webb Space Telescope's (JWST) Integrated Science Instrument Module (ISIM) can be seen as the black composite framework in this image. The gold-coloured frame under it is the test frame.

The silver-wrapped instrument on the left is the European-provided MIRI (Mid InfraRed Instrument). The gold-coloured instrument, partly visible inside the frame, is the Canadian-provided FGS/NIRISS (Fine Guidance Sensor/Near Infrared Imager and Slitless Spectrograph).

This image was taken while the ISIM was still inside the NASA Goddard Space Flight Center's Space Systems Development and Integration Facility (SSDIF) cleanroom.

Last Update: 1 September 2019
