Hubble Looks Through Cosmic Zoom Lens (6 cropped images)

Hubble Looks Through Cosmic Zoom Lens (6 cropped images)


Depicts: Abell 1689
Copyright: NASA, N. Benitez (JHU), T. Broadhurst (Racah Institute of Physics/The Hebrew University), H. Ford (JHU), M. Clampin (STScI), G. Hartig (STScI), G. Illingworth (UCO/Lick Observatory), the ACS Science Team and ESA

A selection of cropped images from a NASA Hubble Space Telescope Advanced Camera for Surveys view of one of the most massive galaxy clusters known, called Abell 1689. These close-ups show "lensed" images of background galaxies that have been brightened and smeared by the gravitational bending of light by the foreground cluster.

The yellow-white objects are the cluster galaxies located 2.2 billion light-years away. The blue arcs are the distorted images of background galaxies located billions of light-years farther away than Abell 1689.

The distribution of both "normal" and dark matter, and the alignment of the background galaxies determine the amount of distortion. In a perfectly aligned gravitational lens the background object would be smeared into an "Einstein ring." Instead, there are numerous ring sections or arcs corresponding to individual galaxies.

Though the galaxy images are distorted, numerous structural details such as star clusters and dust lanes are magnified. These would not normally be resolved without the lensing effect of the foreground cluster. Red objects in the field may be nearby cool stars, or galaxies at great distances. Images of the same galaxies are also mirrored on either side of the cluster. These distortions yield clues to dark matter in space, and the curvature of the universe. They also beautifully demonstrate Einstein's theory of general relativity that predicted that gravity warps space. This representative color image is a composite of visible-light and near-infrared exposures taken in June 2002.

Last Update: 1 September 2019
