Gaia BAM OMA bar #2 at a Delivery Review Board

Gaia BAM OMA bar #2 at a Delivery Review Board


Date: 29 March 2012
Satellite: Gaia
Depicts: Gaia BAM OMA bar #2
Copyright: TNO/Fred Kamphues

One of the two bars that make up the Gaia Basic Angle Monitor (BAM) Opto-Mechanical Assembly (OMA). The two mirrors that direct the measurement beams onto one of the main mirrors are at the top of the vertical columns. The bar is connected to the test/handling fixture using isostatic mounts, as will be the case when it is attached to the Gaia payload torus.

(Read more about the BAM in the accompanying article 'Basic Angle Monitor delivered for integration', in the right-hand menu.)
