Back Both PACS Photoconductor Arrays

Both PACS Photoconductor Arrays


Date: 19 September 2007
Satellite: Herschel
Depicts: Photoconductor arrays for both spectrometer channels
Copyright: MPE, Garching, Germany

Stressed and unstressed Ge:Ga photoconductor arrays for the long- and short-wave spectrometer channels of PACS (57-210 µm) before integration into their housings. The light cones (orange openings) in front of each detector pixel act as field optics to collect the light in the focal plane and couple it into the individual detector elements.
Last Update: 1 September 2019
