Back EPIC PN Camera

EPIC PN Camera


Date: 19 December 1998
Satellite: XMM-Newton
Depicts: EPIC-PN camera

The EPIC PN detector has a single chip, whose design represents a radical departure from the integrated circuit conception of current MOS CCDs. In contrast to the MOS camera, the PN-detector has a 400 x 400 pixel matrix of 6 cm x 6 cm, monolithically fabricated on a four inch high purity silicon wafer. The 36 cm² sensitive area makes it the largest X-ray CCD detector ever built.
Last Update: 1 September 2019
