INTEGRAL Spectrometer SPI
![](https://cdn.sci.esa.int/documents/33682/35393/1567219883494-SPI-cutaway410.gif)
Date: 07 June 2000
Satellite: INTEGRAL
Depicts: SPI
Copyright: ESA
Cut-away view of the Spectrometer on INTEGRAL (SPI)
- Detector:
- Coded Mask:
- Veto system:
|
yellow hexagonal bars in middle |
|
at the top |
|
orange cylinders, below detector and on the side |
