Elliptical impact crater in Hesperia Planum

Elliptical impact crater in Hesperia Planum


Date: 03 January 2006
Satellite: Mars Express
Copyright: ESA/DLR/FU Berlin, CC BY-SA IGO 3.0

This image, taken by the High Resolution Stereo Camera (HRSC) on board ESA's Mars Express spacecraft, shows a large elliptical impact crater in the Hesperia Planum region of Mars.

The HRSC obtained the image during orbit 368 with a ground resolution of approximately 16.7 metres per pixel. The scene shows the region of Hesperia Planum, at approximately 35.3° South and 118.7° East. North is to the left.

A large elliptical impact crater is visible within this image, measuring approximately 24.4 km long, 11.2 km wide and reaching a maximum depth of approximately 650 metres below the surrounding plains.

Ejecta from this impact can be seen extending away from the crater, including two prominent lobes of material north-west and south-east of the crater.

The large circular feature, partly cut off by the border of the image, has a diameter of roughly 45 km.

This appears to be an impact crater that was subsequently resurfaced by lava flows, preserving the outline of the underlying crater. The curving features visible in the north of the image, known as wrinkle ridges, are caused by compressional tectonics.

While the majority of impact craters are relatively circular, the elliptical shape of this impact crater suggests a very low impact angle (less than 10°).

The long axis of the impact crater is viewed as the impacting direction of the projectile. Similar elliptical craters are observed elsewhere on Mars, as well as on our Moon.

The colour scene has been derived from the three HRSC-colour channels and the nadir channel.


This work is licensed under a Creative Commons Attribution-ShareAlike 3.0 IGO License. Creative Commons License



Last Update: 1 September 2019
