Snapshots of Titan's north polar cloud

Snapshots of Titan's north polar cloud


Date: 08 March 2012
Satellite: Cassini
Depicts: Snapshots of Titan's north polar cloud
Copyright: NASA/JPL-Caltech/University of Arizona/CNRS/LPGNantes

This series of false-colour images obtained by NASA's Cassini spacecraft shows the dissolving cloud cover over the north pole of Saturn's moon Titan. The images, obtained by Cassini's visual and infrared mapping spectrometer (VIMS), cover 2006 to 2009, when Titan was transitioning from northern winter to northern spring. In 2006, the north polar cloud appeared dense and opaque. But in spectrometer images obtained around the 2009 equinox, when the Sun was directly over Saturn and Titan's equators and northern winter was turning into spring, the cloud appeared much thinner and patchier. The dissipating cloud allowed scientists to see the underlying northern lakes and seas, including Kraken Mare. The northern seas and lakes on the surface below, made of liquid hydrocarbons, look like dark jigsaw puzzle pieces in the false-colour images.

Scientists colourised the VIMS image by assigning red, green and blue to the parts of the infrared spectrum around 5 micrometres, 2.8 micrometres and 2.03 micrometres, respectively. The images create a kind of time-lapse series from 28 December 2006 to 6 June 2009.

The Cassini-Huygens mission is a cooperative project of NASA, the European Space Agency and the Italian Space Agency. NASA's Jet Propulsion Laboratory, a division of the California Institute of Technology in Pasadena, manages the mission for NASA's Science Mission Directorate, Washington, DC. The Cassini orbiter was designed, developed and assembled at JPL. The visual and infrared mapping spectrometer was built by JPL, with a major contribution by the Italian Space Agency (ASI). The visual and infrared mapping spectrometer science team is based at the University of Arizona, Tucson.

(This image was originally published on the NASA website.)
