NAVCAM top 10 at 10 km - 5

NAVCAM top 10 at 10 km - 5


Date: 10 November 2014
Satellite: Rosetta
Depicts: Comet 67P/Churyumov–Gerasimenko
Copyright: ESA/Rosetta/NAVCAM, CC BY-SA IGO 3.0

In this scene from the large lobe of Comet 67P/Churyumov–Gerasimenko, sets of long, parallel grooves and ridges in the foreground draw the eye up to a block of layered material (appearing as vertically stacked layers in this orientation) in the centre of the frame. This ridge traces up to a peak in the distance, through a cascade of boulders. To the left, flat-topped steps contrast against a ‘pinnacle’ seen against the horizon. To the right, a patch of brighter material lies crumbled at the base of a steep wall – perhaps signalling material that has been freshly exposed.

In a different orientation, the ‘peak’ actually appears as a flat ridge that slopes down onto a flat plateau, showing the importance of viewing features from different angles in order to understand them fully.

This single-frame NAVCAM image measures 1024 x 1024 pixels. It was captured from a distance of 9.8 km from the centre of the comet (8.8 km from the surface) at 22:18 GMT on 23 October 2014. At this distance, the image resolution is 83.5 cm/pixel and the size of the image is 855 x 855 m.


This work is licensed under a Creative Commons Attribution-ShareAlike 3.0 IGO License. Creative Commons License
