Comet 67P/C-G on 22 January 2015 - NavCam mosaic

Comet 67P/C-G on 22 January 2015 - NavCam mosaic


Date: 01 February 2015
Satellite: Rosetta
Depicts: Comet 67P/Churyumov-Gerasimenko
Copyright: ESA/Rosetta/NAVCAM, CC BY-SA IGO 3.0

Mosaic of four images taken by Rosetta's navigation camera (NAVCAM) on 22 January 2015 at 28.0 km from the centre of comet 67P/Churyumov-Gerasimenko. The image scale is about 2.4 m/pixel.

The images used for this mosaic were taken in sequence as a 2×2 raster over a short period af about twenty minutes. Rotation and translation of the comet during the imaging sequence make it difficult to create an accurate mosaic, and there may be some spurious spatial and intensity features as a result of the mosaic-making sequence, so always refer to the individual frames before performing any detailed comparison or drawing conclusions about any strange structures or low intensity extended emission.

The images have been cleaned to remove the more obvious bad 'pixel pairs' and cosmic ray artefacts, and intensities have been scaled.

The mosaic has been slightly rotated and cropped and covers 4.4 × 4.4 km. Some contrast enhancement has been applied.

The four individual full-frame images are also available as related images in the right-hand menu.

More images of comet 67P/Churyumov-Gerasimenko can be found in the '67P - by Rosetta' collection.
